3M7180 Vertical steel ball grinding machine
Category:
Description
Main technical parameters:
| Items and specifications | Parameters |
|
Working range |
φ3~ φ20mm |
|
Dimension of plates |
ODφ800×IDφ360×W90mm |
|
Dimension of wheels |
ODφ800×IDφ360×W100mm |
|
Speed of main shaft |
40~120 r/min(frequency conversion) |
|
Ball load capacity |
300kg |
|
Main motor power |
22kW |
Main structural features:
1.Vertical layout, large cycle machining;
2.Suitable for the hard grinding process;
3.The rotation of main shaft and turntable adopt frequency conversion speed regulation;
4.Hydraulic drive pressure, mechanical pressure preservation by compression spring and constant pressure nut locking;
5.Adopt end face bearing with high capacity;
6.The main shaft bearing adopts the mechanical seal structure, which eliminates the hidden danger of the main shaft oil leakage;
7.The main transmission uses reduction box with a pair of increase modulus and widening gears. The power is transmitted to the spindle through the output shaft of the bevel gear. The transmission structure is simple and reliable;
8.With mechanical grinding wheel dresser driven by belt motor;
9.Adopt small cycle processing in accordance with the requirements (without turntable).
